Descrição
Características
- Válvula rotatória SOMENTE para mercados específicos – NÃO está em acordo com os requisitos ANSI e ISO
Part number 6151604020
Model CP3450-12ACR4
Spindle thread 3/8-24
Wheel size 100 mm 4″
Cup wheel Diam. – –
Free speed 12000 rpm
Power 810 W 1.1 hp
Length 230.5 mm 9.22″
Net weight 1.46 kg 3.21 lb
Rear exhaust Rear exhaust
Noise level 93.9 db(A)
Sound Power 104.9 db(A)
Vibration (ISO-8662-4) 4.6 m/s²
Vibration α (ISO-28927-1) 8.12 m/s²
Vibration K (ISO-28927-1) 2.88 m/s²
Average air consumption 8.5 l/s 18.02 cfm
Average air consumption 510 l/mn 18.02 cfm
Actual air consumption 17 l/s 36.04 cfm
Actual air consumption 1020 l/mn 36.04 cfm
Free speed air consumption 20.2 l/s 42.82 cfm
Min. hose size 10 mm 3/8″
Box dimensions 250x155x107
